Brand
Yealink
Description
Yealink MCoreKit-C5U Microsoft Teams Rooms System (MCoreKit-C5U-MS)
SKU
MCOREKITC5U-MS
Package Content
MCore 4,Gen-4 Mini-PC
MTouch Plus, Gen-3 touch panel
RoomSensor
Preload
Windows 11 IoT Enterprise X64
Windows 11 IoT Enterprise License
Microsoft Teams Rooms App
Yealink RoomConnect
MCore 4, Gen-4 Mini-PC
Processor: Intel Ultra5 125H
Memory: 16GB(2*8GB) DDR5
Storage: 256GB SSD
Microphones
Built-in 16 MEMS microphone array
10-meter pickup distance
BIOS feature:
3x HDMI video output
-CEC
-EDID
TPM2.0
Kernel DMA
Interface:
1 x HDMI-Out 2.1 port
2 x HDMI-Out 2.0 port
1 x HDMI-In port
4 x USB3.0 Type-A Port
1 x MTouch Port (RJ-45)
1 x LAN port for AV network
1 x 10/100/1000 Gigabit Ethernet Port
1 x Power Supply Port
1 x 3.5mm headphone Port
1 x Reset port
1 x Security Slot
WiFi: IEEE 802.11 a/b/g/n/ac/ax
Bluetooth: BT 5.2
MTouch Plus
Physical Features:
11.6-inch narrow bezel IPS display
Angle between screen and desktop (30° ~ 70°) Adjustable angle of support frame (50° ~ 180°)
Function Features：
1920 x 1080 video resolution
Support wired and wireless (with WPP30) content sharing
Support external PD power supply to power the sharing device
Support HDMI/USB-C video input
Support desktop placement, desktop fixed, wall-mounted deployment
RoomSensor
Detection angle: 120°
Adjustable detection angle: ±20°
Operating temperature: 0-40
Operating humidity: 10-95%
Warranty
24 months
