| PERFORMANCE |
| Processor | Intel® Core Ultra 5 228V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.5GHz, 8MB |
| AI PC Category | Copilot+ PC
|
| NPU | Integrated Intel® AI Boost, up to 40 TOPS |
| Graphics | Integrated Intel® Arc™ Graphics 130V |
| Chipset | Intel® SoC Platform |
| Memory | 32GB Soldered LPDDR5x-8533, MoP Memory |
| Memory Slots | Memory soldered to systemboard, no slots, dual-channel |
| Max Memory | 32GB soldered memory, not upgradable |
| Storage | 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Storage Slot | One M.2 2242 PCIe® 4.0 x4 slot |
| Max Storage Support
| One drive, up to 1TB M.2 2242 SSD |
| Card Reader | microSD Card Reader |
| Audio Chip | SoundWire®, Cirrus Logic® CS42L43 codec |
| Speakers | 4 stereo speakers, 2W x2 (woofers), 2W x2 (tweeters), optimized with Dolby Atmos®, Smart Amplifier (AMP) |
| Microphone | 4x, Array |
| Camera | 5.0MP + IR with E-shutter |
| Battery | 70Wh |
| Power Adapter | 65W USB-C® Slim (2-pin, Wall-mount) |
| DESIGN |
| Display | 14" 2.8K WQXGA+ (2880x1800) OLED 1100nits (peak) / 500nits (typical) Glossy, 100% DCI-P3, 120Hz, Eyesafe®, Dolby Vision®, DisplayHDR™ True Black 1000, X-Rite®, PureSight Pro |
| Touchscreen | None |
| Screen-to-Body Ratio | 90% AAR (active area ratio) |
| Color Calibration | X-Rite® Factory Color Calibration |
| Pen | Pen Not Supported |
| Keyboard | Backlit, Thai |
| Touchpad | Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 80 x 135 mm (3.15 x 5.31 inches) |
| Dimensions (WxDxH)
| 312 x 219.3 x 13.9 mm (12.28 x 8.63 x 0.55 inches) |
| Weight
| Starting at 1.19 kg (2.62 lbs) |
| Case Color | Luna Grey |
| Case Material | Aluminium (Top), Aluminium (Bottom) |
| Surface Treatment | Aluminium Stamping (Anodized with Sandblasting) |
| SOFTWARE |
| Operating System | Windows® 11 Home Single Language, English |
| Bundled Software | Office Home 2024 + Lenovo® AI Now |
| CONNECTIVITY |
| WLAN + Bluetooth | Wi-Fi® 7, 802.11be 2x2 + BT5.4
|
| WWAN | Non-WWAN |
| Ethernet | No Onboard Ethernet |
| Standard Ports | - 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x microSD card reader
|
| Docking | Various docking solutions are supported via Thunderbolt™. For more compatible docking solutions, please visit Docking for Yoga® Slim 7 14ILL10 |
| SECURITY & PRIVACY |
| Security Chip | Firmware TPM 2.0 |
| Fingerprint Reader | None |
| Other Security | - Ultrasonic Human Presence Detection
- E-shutter
- IR camera for Windows® Hello (facial recognition)
|
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y Premium Care -IPPREM (ESS) |
| ACCESSORIES |
| Bundled Accessories | None |
| CERTIFICATIONS |
| Green Certifications | - Carbon Neutral Certified
- ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
|
| Mil-Spec Test | MIL-STD-810H military test passed (21 test items) |
| Other Certifications | - Intel® Evo™ Platform
- Eyesafe® Certified 2.0
- TÜV Rheinland® Flicker Free
- TÜV Rheinland® Low Blue Light (Hardware Solution)
|
| MODEL INFORMATION |
| Model | 83JX001FTA |
| Machine Type | 83JX |
| Region | ASEAN |
| Country/Region | Thailand |
| TopSeller | Yes |
| EAN / UPC / JAN | 198156517616 |
| Announce Date | 2025-01-01 |
| End of Support | 2031-02-17 |
