| PERFORMANCE |
| Processor | Intel® Core Ultra 9 285H, 16C (6P + 8E + 2LPE) / 16T, Max Turbo up to 5.4GHz, 24MB Intel Smart Cache |
| AI PC Category | AI PC |
| NPU | Integrated Intel® AI Boost, up to 13 TOPS |
| Graphics | Integrated Intel® Arc™ 140T GPU |
| Chipset | Intel® SoC Platform |
| Memory | 32GB Soldered LPDDR5x-8533 |
| Memory Slots | Memory soldered to systemboard, no slots, dual-channel |
| Max Memory | 32GB soldered memory, not upgradable |
| Storage | 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Storage Slot | Two M.2 slots • One M.2 2242 PCIe® 4.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot |
| Max Storage Support
| Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB |
| Card Reader | SD Card Reader |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC3306 codec |
| Speakers | 4 stereo speakers, 2W x2 (woofers), 2W x2 (tweeters), optimized with Dolby Atmos®, Smart Amplifier (AMP) |
| Microphone | 4x, Array |
| Camera | 5.0MP + IR with E-shutter |
| Battery
| 84Wh |
| Power Adapter | 100W USB-C® Slim (3-pin) |
| DESIGN |
| Display | 14.5" 3K (3000x1876) OLED 1000nits (peak) / 500nits (typical) Glossy / Anti-fingerprint, 100% DCI-P3, 120Hz, Eyesafe®, Dolby Vision®, Flicker Free, DisplayHDR™ True Black 1000, Glass, Touch, X-Rite®, PureSight Pro |
| Touchscreen | On-cell, 10-point Multi-touch |
| Screen-to-Body Ratio | 90.8% AAR (active area ratio) |
| Color Calibration | X-Rite® Factory Color Calibration |
| Pen | None |
| Keyboard | Backlit, Thai |
| Touchpad | Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 80 x 135 mm (3.15 x 5.31 inches) |
| Dimensions (WxDxH)
| 325.3 x 228.1 x 16.9 mm (12.81 x 8.98 x 0.67 inches) |
| Weight
| Starting at 1.54 kg (3.39 lbs) |
| Case Color | Luna Grey |
| Case Material | Aluminium (Top), Aluminium (Bottom) |
| Surface Treatment | Aluminium Stamping (Anodized with Sandblasting) |
| SOFTWARE |
| Operating System | Windows® 11 Home Single Language, English |
| Bundled Software | Microsoft® 365 Basic + Office Home 2024 + Lenovo® AI Now |
| CONNECTIVITY |
| WLAN + Bluetooth | Wi-Fi® 7, 802.11be 2x2 + BT5.4 |
| WWAN | WWAN Not Supported |
| Ethernet | No Onboard Ethernet |
| Standard Ports | - 1x USB-A (USB 5Gbps), Always On
- 1x USB-A (USB 5Gbps)
- 2x Thunderbolt™ 4, with USB PD 65-100W and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x SD card reader
|
| Docking | Various docking solutions are supported via Thunderbolt™. For more compatible docking solutions, please visit Docking for Yoga® Pro 7 14IAH10 |
| SECURITY & PRIVACY |
| Security Chip | Firmware TPM 2.0 |
| Fingerprint Reader | No Fingerprint Reader |
| Other Security | - E-shutter
- IR camera for Windows® Hello (facial recognition)
|
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y ADP - IPPREM (ESS), 3Y Premium Care -IPPREM (ESS) |
| ACCESSORIES |
| Bundled Accessories | None |
| CERTIFICATIONS |
| Green Certifications | - Carbon Neutral Certified
- ENERGY STAR® 9.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
|
| Mil-Spec Test | MIL-STD-810H military test passed (21 test items) |
| Other Certifications | - Eyesafe® Certified 2.0
- Intel® Evo™ Platform
- TÜV Rheinland® Flicker Free
- TÜV Rheinland® Low Blue Light (Hardware Solution)
|
| MODEL INFORMATION |
| Model | 83KF002MTA |
| Machine Type | 83KF |
| Region | ASEAN |
| Country/Region | Thailand |
| TopSeller | Yes |
| EAN / UPC / JAN | 198158824248 |
| Announce Date | 2025-04-08 |
| End of Support | 2031-04-03 |
