| PERFORMANCE |
| Processor | Intel® Core Ultra 7 258V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.8GHz, 12MB Intel Smart Cache |
| AI PC Category | Copilot+ PC |
| NPU | Integrated Intel® AI Boost, up to 47 TOPS |
| Graphics | Integrated Intel® Arc™ Graphics 140V |
| Chipset | Intel® SoC Platform |
| Memory | 32GB Soldered LPDDR5x-8533, MoP Memory |
| Memory Slots | Memory soldered to systemboard, no slots, dual-channel |
| Max Memory | 32GB soldered memory, not upgradable |
| Storage | 1TB SSD M.2 2280 PCIe® 5.0x4 Performance NVMe® Opal 2.0
|
| Storage Slot | Models with V or H series processor: one M.2 2280 PCIe® 5.0 x4 slot |
| Max Storage Support
| One drive, up to 2TB M.2 2280 SSD |
| Card Reader | None |
| Audio Chip | Lunar Lake: SoundWire®, Realtek® ALC713 codec |
| Speakers | Stereo speakers, 2W x2, Dolby Atmos® |
| Microphone | 2x, 360° |
| Camera | FHD 1080p + IR Discrete with Privacy Shutter |
| Battery | 57Wh |
| Power Adapter | 65W USB-C® Nano GaN (2-pin, Wall-mount) |
| DESIGN |
| Display | 14" 2.8K (2880x1800) OLED 500nits Anti-glare / Anti-reflection / Anti-smudge, 100% DCI-P3, 120Hz VRR, DisplayHDR™ True Black 500, Dolby Vision® |
| Touchscreen | None |
| Screen-to-Body Ratio | 89.2% |
| Pen | Pen Not Supported |
| Keyboard | Backlit, Thai |
| Touchpad | Trackpad |
| Dimensions (WxDxH)
| 312.80 x 214.75 x 8.08/14.37 (front/rear), 16.95 (maximum) mm; 12.31 x 8.45 x 0.32/0.56 (front/rear), 0.67 (maximum)inches |
| Weight
| Starting at 986 g (2.17 lbs) |
| Case Color | Black, Paint |
| Case Material | Carbon Fiber (Top), Magnesium (Bottom) |
| SOFTWARE |
| Operating System | Windows® 11 Pro, English (US) / English (UK) |
| Bundled Software | Intel® Connectivity Performance Suite + Lenovo® AI Now |
| CONNECTIVITY |
| WLAN + Bluetooth | Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4, vPro®
|
| WWAN | WWAN Not Supported |
| SIM Card | None |
| Ethernet | No Onboard Ethernet
|
| NFC | None |
| Standard Ports | - 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
|
| Optional Ports (configured) | None |
| Docking | Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad X1 Carbon Gen 13 Aura Edition |
| SECURITY & PRIVACY |
| ThinkShield | ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more detials, visit here |
| Security Chip | Discrete TPM 2.0 Enabled |
| Physical Locks | Kensington® Nano Security Slot, 2.5 x 6 mm |
| Smart Card Reader | None |
| Fingerprint Reader | Touch Style, Match-on-Chip, in Keyboard Key |
| Other Security | - Camera privacy shutter
- IR camera for Windows® Hello (facial recognition)
|
| MANAGEABILITY |
| System Management | Non-vPro® |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y Premier Support Plus upgrade from 1Y Courier/Carry-in |
| ACCESSORIES |
| Bundled Accessories | None |
| CERTIFICATIONS |
| Green Certifications | - ENERGY STAR® 9.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
- TCO Certified, generation 10
|
| Mil-Spec Test | MIL-STD-810H military test passed |
| Other Certifications | - Eyesafe® Certified 2.0
- Intel® Evo™ Platform
- SGS High Performance Al PC Certification
|
