| PERFORMANCE |
| Processor | Intel® Core Ultra 7 255H, 16C (6P + 8E + 2LPE) / 16T, Max Turbo up to 5.1GHz, 24MB Intel Smart Cache |
| AI PC Category | AI PC
|
| NPU | Integrated Intel® AI Boost, up to 13 TOPS |
| Graphics | Integrated Intel® Arc™ 140T GPU Functions as Intel Graphics |
| Chipset | Intel® SoC Platform |
| Memory | 1x 32GB SODIMM DDR5-5600 |
| Memory Slots | Arrow Lake: two DDR5 SODIMM / CSODIMM slots, dual-channel capable |
| Max Memory | Arrow Lake: up to 64GB DDR5-5600 |
| Storage | 1TB SSD M.2 2280 PCIe® 5.0x4 Performance NVMe® Opal 2.0
|
| Storage Slot | Models with V or H series processor: one M.2 2280 PCIe® 5.0 x4 slot |
| Max Storage Support
| One drive, up to 2TB M.2 2280 SSD |
| Card Reader | None |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
| Speakers | Stereo speakers, 2W x2, Dolby Audio™ |
| Microphone | 2x, 360° |
| Camera | 5.0MP with Privacy Shutter |
| Battery | 52.5Wh |
| Power Adapter | 65W USB-C® Slim GaN (3-pin) |
| DESIGN |
| Display | 14" WUXGA (1920x1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz, DBEF5
|
| Touchscreen | None |
| Screen-to-Body Ratio | 85.73% |
| Pen | Pen Not Supported |
| Keyboard | Backlit, Thai |
| Dimensions (WxDxH)
| 315.9 x 223.7 x 10.9/16.13 (front/rear), 21.8 (maximum) mm; 12.44 x 8.81 x 0.43/0.64 (front/rear), 0.86 (maximum) inches |
| Weight
| Starting at 1.46 kg (3.22 lbs) |
| Case Color | Black |
| Case Material | PC + 20% CF (Top), PC + 20% CF (Bottom) |
| SOFTWARE |
| Operating System | Windows® 11 Pro, English (US) / English (UK) |
| Bundled Software | Lenovo® AI Now |
| CONNECTIVITY |
| WLAN + Bluetooth | Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4 |
| WWAN | WWAN Not Supported |
| SIM Card | None |
| Ethernet | 100/1000M (RJ-45) |
| NFC | None |
| Standard Ports | - 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (RJ-45)
|
| Optional Ports (configured) | None |
| Docking | Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad T14 Gen 6 (Intel) |
| SECURITY & PRIVACY |
| ThinkShield | ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more detials, visit here |
| Security Chip | Discrete TPM 2.0 Enabled |
| Physical Locks | Kensington® Nano Security Slot, 2.5 x 6 mm |
| Smart Card Reader | None |
| Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
| Other Security | Camera privacy shutter (camera models) |
| MANAGEABILITY |
| System Management | Non-vPro® |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y Premier Support Plus upgrade from 1Y Courier/Carry-in |
| ACCESSORIES |
| Bundled Accessories | None |
| CERTIFICATIONS |
| Green Certifications | - ENERGY STAR® 9.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
- TCO Certified, generation 10
|
| Mil-Spec Test | MIL-STD-810H military test passed |
