| PERFORMANCE |
| Processor | Intel® Core Ultra 5 225F, 10C (6P + 4E) / 10T, Max Turbo up to 4.9GHz, 20MB Intel Smart Cache |
| AI PC Category | AI-Powered Gaming PC
|
| NPU | Integrated Intel® AI Boost, up to 13 TOPS |
| Graphics | NVIDIA® GeForce RTX™ 4060 8GB GDDR6 242 AI TOPS |
| Chipset | Intel® B860 Chipset |
| Memory | 2x 16GB UDIMM DDR5-5600 |
| Memory Slots | Four DDR5 UDIMM slots, dual-channel capable |
| Max Memory
| Up to 64GB DDR5-6400 |
| Storage | 1TB SSD M.2 2280 PCIe® 4.0x4 NVMe® |
| Max Storage Support
| Up to four drives, 3x M.2 SSD + 1x open 3.5 HDD Bay • 3.5" HDD bay only for customer self upgrade • M.2 SSD up to 2TB each |
| Card Reader | None |
| Optical | None |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC623 codec |
| Speakers | No speakers |
| Power Supply | 500W 85% |
| DESIGN |
| Keyboard | None |
| Mouse | None |
| Expansion Slots | - One PCIe® 5.0 x16
- One PCIe® 3.0 x4
- Four M.2 slots (one for WLAN, three for SSDs)
|
| Case Color | Eclipse Black (Transparent cover) + airflow with ARGB + Inner Decorate Cover |
| System Lighting | Legion Logo Lighting |
| Chassis | Transparent Cover + Inner Decorate Cover |
| Cooler | PCH Heatsink + SSD Heatsink + VRM Heatsink + 150W airflow 120MM-Fan with ARGB light |
| System Fan | 1x Rear with ARGB + 2x Top with ARGB + 2x Buttom with ARGB |
| Pen | Pen Not Supported |
| Form Factor | Tower (30L) |
| Dimensions (WxDxH) | 211 x 490.4 x 414 mm (8.3 x 19.3 x 16.29 inches) |
| Weight
| Around 15 kg (33.06 lbs) |
| CONNECTIVITY |
| WLAN + Bluetooth | Wi-Fi® 7, 802.11be 2x2 + BT5.4
|
| WWAN | WWAN Not Supported |
| Ethernet | 2.5GbE RTL8125BG |
| Top Ports | - 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x headphone / microphone combo jack (3.5mm)
|
| Rear Ports
| - 1x USB-C® (USB 10Gbps / 3.2 Gen 2)
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 4x USB-A (Hi-Speed USB / USB 2.0)
- 1x Ethernet (2.5GbE RJ-45)
- 1x power connector
- 3x audio out (5.1 channel)
|
| SECURITY & PRIVACY |
| Security Chip | Firmware TPM 2.0 integrated in chipset |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y Legion Ultimate Support -Idea DT (ESS) |
| CERTIFICATIONS |
| Green Certifications | RoHS compliant |
| SOFTWARE |
| Operating System | Windows® 11 Home Single Language, English |
| Bundled Software | Lenovo® AI Now |
