| PERFORMANCE |
| Processor | Intel® Core Ultra 9 275HX, 24C (8P + 16E) / 24T, Max Turbo up to 5.4GHz, 36MB |
| AI PC Category | AI-Powered Gaming PC
|
| NPU | Integrated Intel® AI Boost, up to 13 TOPS |
| Graphics | NVIDIA® GeForce RTX™ 5080 16GB GDDR7, Boost Clock 2287MHz, TGP 175W, 1334 AI TOPS |
| Chipset | Intel® HM870 Chipset |
| Memory | 2x 16GB CSODIMM DDR5-6400 |
| Memory Slots | Two DDR5 CSODIMM slots, dual-channel capable |
| Max Memory
| Up to 32GB DDR5-6400 offering |
| Storage | 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Storage Slot | Two M.2 slots • One M.2 2280 PCIe® 5.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot |
| Max Storage Support
| Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 2TB |
| Optical | None |
| Card Reader | None |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC3306 codec |
| Speakers | 4 stereo speakers, 2W x2 (woofers), 2W x2 (tweeters), optimized with Nahimic Audio, Smart Amplifier (AMP) |
| Microphone | 2x, Array |
| Camera | 5.0MP with E-shutter |
| Battery | 80Wh |
| Power Adapter | 400W Slim Tip (3-pin) |
| Special Features | AI Chip: LA3 |
| DESIGN |
| Display | 16" WQXGA (2560x1600) OLED 500nits (Typical) / 1100nits (Peak) Glossy, 100% DCI-P3, 240Hz, DisplayHDR™ True Black 1000, Dolby Vision®, G-SYNC®, Low Blue Light, High Gaming Performance, Flicker Free |
| Touchscreen | None |
| Screen-to-Body Ratio | 92% AAR (active area ratio) |
| Color Calibration | Factory Color Calibration |
| Pen | Pen Not Supported |
| Keyboard | Per-key RGB Backlit, Thai |
| Touchpad | Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches) |
| Dimensions (WxDxH)
| 364.38 x 275.94 x 21.9-26.65 mm (14.35 x 10.86 x 0.86-1.05 inches) |
| Weight
| Starting at 2.57 kg (5.67 lbs) |
| Case Color | Eclipse Black |
| Case Material | Aluminium (Top), Aluminium (Bottom) |
| Surface Treatment | Anodizing Sandblasting |
| SOFTWARE |
| Operating System | Windows® 11 Home Single Language, English |
| Bundled Software | Office Trial |
| CONNECTIVITY |
| WLAN + Bluetooth | Wi-Fi® 7, 802.11be 2x2 + BT5.4
|
| WWAN | Non-WWAN |
| Ethernet | 2.5GbE (RJ-45) |
| Standard Ports | - 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 2.1
- 1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer and DisplayPort™ 2.1)
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (2.5GbE RJ-45)
- 1x Power connector
|
| Docking | Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for Legion Pro 7 16IAX10H |
| SECURITY & PRIVACY |
| Security Chip | Firmware TPM 2.0 Enabled |
| Fingerprint Reader | None |
| Other Security | E-shutter |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 4Y Legion Ultimate Support -IPPREM (ESS) |
| ACCESSORIES |
| Bundled Accessories | 4 Switchable Keycaps |
| CERTIFICATIONS |
| Green Certifications | |
| Other Certifications | - TÜV Rheinland® Flicker Free
- TÜV Rheinland® High Gaming Performance
- TÜV Rheinland® Low Blue Light (Hardware Solution)
|
| MODEL INFORMATION |
| Model | 83F5004DTA |
| Machine Type | 83F5 |
| Region | ASEAN |
| Country/Region | Thailand |
| TopSeller | Yes |
| EAN / UPC / JAN | 198156895301 |
| Announce Date | 2025-02-26 |
| End of Support | 2031-03-08 |
