Technical Information
Screen Size Class
27"
Viewable Screen Size
27"
Screen Mode
4K UHD
Panel Technology
In-plane Switching (IPS) Black Technology
Response Time Details
Aspect Ratio
16:9
Pixel Pitch
0.1554 mm x 0.1554 mm
Horizontal Viewing Angle
178°
Vertical Viewing Angle
178°
Mount Type
Panel Mount
Backlight Technology
LED Edgelight System
HDCP Supported
Yes
Maximum Adjustable Height
5.91"
Tilt Angle
-5° to 21°
Swivel Angle
-45° to 45°
Pivot Angle
-90° to 90°
Features
- VESA DisplayHDR 600
- sRGB
- Eye Comfort Technology
- Low reflectance with anti-glare and hard-coating 3H
- Picture by Picture
- Picture in Picture
- Color Calibration
- Ambient Light Sensor
- Cable Lock Slot
- Security Lock
- BFR Free
- PVC Free
- Arsenic-free Glass
- Mercury-free
- Narrow Bezel
Horizontal Frequency
30 kHz to 275 kHz
Vertical Frequency
48 Hz to 120 Hz
Adjustable Stand
Yes
Stand Adjustments
Stand Included
Yes
Glass Hardness
3H
Soundbar Compatibility
Optional soundbar (sold separately)
Video
Maximum Resolution
3840 x 2160
Standard Refresh Rate
120 Hz
Color Supported
1.07 Billion Colors
Native Contrast Ratio
3,000:1
Brightness
Color Gamut
- DCI-P3 99% (CIE1976) (typical)
- Display P3 99%
- sRGB 100% (CIE1931) (typical)
- BT.709 100%
- Delta E <1.5 (Average)
Pixel Per Inch (PPI)
163
Interfaces/Ports
Connectivity
- 1 DisplayPort 1.4 port with DSC support (DRR for Microsoft Windows)
- 1 DisplayPort 1.4 port out
- 1 HDMI port (Supports up to UHD 3840 x 2160 120Hz FRL, VRR as per specified in HDMI2.1)
- 1 Thunderbolt 4 upstream port (DP1.4 (HDCP 2.2) with DSC support, PD: Up to 140W EPR , 2/4 Lanes switching)
- 1 Thunderbolt 4 downstream port (Downstream, Daisy Chain, 15 W)
- 1 USB-C (USB 10Gbps KVM) upstream port
- 1 Analog 2.0 audio line out port (3.5 mm jack)
- 4 USB Type-A ports 10Gbps
- 1 RJ45 Ethernet port, 2.5GbE
- Quick Access port:
- 1 USB Type-A 10Gbps port with BC 1.2
- 2 USB-C 10Gbps downstream ports
USB Type-C (Power Delivery)
Up to 140W EPR
Audio Line Out
Yes
Built-in Devices
Built-in Devices
Ambient Light Sensor
Environmental Conditions
Operating Temperature Range
32°F (0°C) to 104°F (40°C)
Non-operating Temperature Range
-4°F (-20°C) to 140°F (60°C)
Operating Humidity Range
10% to 80% (Non-condensing)
Non-operating Humidity Range
5% to 90% (Non-condensing)
Maximum Operating Altitude
16400 ft
Maximum Non-operating Altitude
40000 ft
Power Description
Input Voltage Range
100V AC to 240V AC
Operating Power Consumption
25.40 W
Standby Power Consumption
0.5 W
Off-Mode Power Consumption
0.3 W
Frequency
Maximum Power Consumption
325 W
Voltage Current
4 Ah
Physical Characteristics
VESA Mount Compatible
Yes
VESA Mount Standard
100 x 100
Height
13.92"
Width
24.11"
Depth
2.19"
Height with Stand
21.09"
Width with Stand
24.11"
Depth with Stand
7.44"
Compressed Height with Stand
15.18"
Extended Height with Stand
21.09"
Weight (Approximate)
11.51 lb
Weight with Stand (Approximate)
15.56 lb
Miscellaneous
Package Contents
- UltraSharp 27 4K Thunderbolt Hub Monitor U2725QE
- Stand
- Drivers and documentation media
- QR Card
- Safety Information
Cables Included
- Power cable
- 1 x DisplayPort-DisplayPort cable - 1.80 m
- 1 x USB Type-A to Type-C upstream cable 1.00 m
- 1 x Thunderbolt 4 passive cable - 1.00 m
Energy Star
Yes
Country of Origin
China
TAA Compliant
Yes
TCO Certified
Yes
Dell Display Manager Compatibility
Yes
Environmentally Friendly
Yes
Environmental Certification
TCO Certified Edge
Energy Efficiency Certification
ENERGY STAR 8.0
Energy Efficiency Compliance
Energy-related Products Directive Lot 5 (ErP Lot 5)
Environmental Compliance
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty
3 Years
Additional Warranty Information
3 Years Limited Hardware and Advanced Exchanged Service
