Cisco Meraki MR42 Cloud management, 802.11ac performance, and a dedicated security radio
-29%

  • Cisco Meraki ทุกรุ่น บังคับซื้อ Subscription (License) & PWR-CORD (อุปกรณ์สำหรับจ่ายไฟ) ด้วยทุกครั้ง
SKU
MR42-HW
ราคา
38,550.00
27,400.00 บาท
สอบถามข้อมูลเพิ่มเติม

Product details of Cisco Meraki MR42 Cloud management, 802.11ac performance, and a dedicated security radio


  • ซื้อพร้อม License MA ทุกครั้ง
  • Usage : General purpose 802.11ac Wave 2 for campus and enterprise
  • Interface : 1 × Gigabit Ethernet port
  • Power : 802.3at/802.3af PoE
    DC power adapter
  • Radios
    • 1 × 802.11b/g/n
    • 1 × 802.11a/n/ac
    • 1 × WIDS/WIPS
    • 1 × Bluetooth
    • 1.9 Gbit/sec max rate
    • 3×3:3 MU-MIMO with beamforming
  • Performance features :
    • 3×3:3 MU-MIMO
    • Priority Voice, Power Save (802.11e/WMM)
    • Hardware-accelerated encryption
    • Band steering




Product Highlights


Ideal use cases
  • Performance-critical wireless LANs
  • High-density environments
Hardware features
  • 3 radios: 2.4 and 5 GHz, dual-band WIDS/WIPS
  • 3-stream 802.11ac Wave 2 and 802.11n, up to 1.9 Gbps
  • Gigabit Ethernet port
  • PoE: Full functionality under 802.3at (compatible with 802.3af)
  • AC adapter available
Cloud management
  • Network-wide visibility and control
  • Self-provisioning for rapid deployment
  • Automatic reporting
  • Seamless firmware updates
Enterprise security
  • 802.1X and native Active Directory integration
  • Air Marshal: real-time WIPS with forensics
  • Stateful Layer 3-7 firewall
  • Identity-based group policies
  • Built-in antivirus scan (NAC)
Guest access
  • 1-click secure guest access
  • Guest isolation firewall
  • Customizable splash pages
  • Integrated Facebook login
RF optimization
  • Dual-concurrent radios with MU-MIMO support
  • Radios optimized for rate-vs-range performance
  • Third radio dedicated to security and RF management
  • Built-in real-time RF spectrum view
  • Cloud-based automatic RF optimization
Layer 7 traffic shaping
  • Classifies hundreds of applications
  • Create per-application bandwidth limits
  • Prioritize productivity apps
  • Restrict or block recreational traffic
Presence location analytics
  • Measure visitor capture rate, visit length, and repeat visit rate
  • Measure visitor trends over time and compare performance across locations
Device management
  • Create device-specific firewall rules
  • Monitor and track device inventory
  • Deploy applications and enforce security settings



Specifications


Radios

  • 2.4 GHz 802.11b/g/n client access radio
  • 5 GHz 802.11a/n/ac client access radio
  • 2.4 & 5 GHz dual-band WIDS/WIPS, spectrum analysis, & location analytics radio
  • 2.4 GHz Bluetooth radio with Bluetooth Low Energy (BLE) and Beacon support
  • Concurrent operation of all four radios
  • Max aggregate frame rate 1.9 Gbit/s
  • Supported frequency bands (country-specific restrictions apply):
    • 2.412-2.484 GHz
    • 5.150-5.250 GHz (UNII-1)
    • 5.250-5.350 GHz (UNII-2)
    • 5.470-5.600, 5.660-5.725 (UNII-2e)
    • 5.725-5.825 GHz (UNII-3)

Antenna

  • Integrated omni-directional antennas (5 dBi gain at 2.4 GHz, 5.5 dBi gain at 5 GHz)
  • Individual antenna elements for each radio

802.11ac Wave 2 & 802.11n Capabilities

  • 3x3 multiple input, multiple output (MIMO) with three spatial streams
  • SU-MIMO and MU-MIMO support
  • Maximal ratio combining (MRC) & beamforming
  • 20 & 40 MHz channels (802.11n)
  • 20, 40, & 80 MHz channels (802.11ac)
  • Up to 256-QAM on both 2.4 & 5 GHz
  • Packet aggregation

Power

  • Power over Ethernet: 37 - 57 V (802.3af compatible, with functionality-restricted 802.3af mode supported)
  • Alternative 12V DC input
  • Power consumption: 20 W max (802.3at)
  • Power over Ethernet injector and DC adapter sold separately

LED Indicators

  • Multi-color & multi-function status indicator

Interfaces

  • 1 × 10/100/1000Base-T Ethernet (RJ45)
  • 1 × DC power connector (5.5mm x 2.5mm, center positive)

Mounting

  • All standard mounting hardware included
  • Desktop, ceiling, and wall mount capable
  • Ceiling tile rail (9/16, 15/16 or 1 ½" flush or recessed rails)
  • Assorted cable junction boxes
  • Bubble level on mounting cradle for accurate horizontal wall mounting

Physical Security

  • Security screw included
  • Kensington lock hard point
  • Anti-tamper cable bay
  • Concealed mount plate

Environment

  • Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)
  • Humidity: 5 to 95% non-condensing

Physical Dimensions

  • 10.0” x 6.1” x 1.5” (253.4 mm x 155.8 mm x 37.1 mm), not including deskmount feet or mount plate
  • Weight: 25 oz (0.7kg)

Security

  • Integrated Layer 7 firewall with mobile device policy management
  • Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal
  • Flexible guest access with device isolation
  • VLAN tagging (802.1q) and tunneling with IPsec VPN
  • PCI compliance reporting
  • WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X
  • EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
  • TKIP and AES encryption
  • Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration

Quality of Service

  • Advanced Power Save (U-APSD)
  • WMM Access Categories with DSCP and 802.1p support
  • Layer 7 application traffic identification and shaping

Mobility

  • PMK and OKC credential support for fast Layer 2 roaming
  • Distributed or centralized Layer 3 roaming

Analytics

  • Embedded location analytics reporting and device tracking
  • Global L7 traffic analytics reporting per network, per device, & per application

Warranty

  • Lifetime hardware warranty with advanced replacement included

Ordering Information

  • MR42-HW
    Meraki MR42 Cloud Managed 802.11ac AP
  • MA-PWR-30W-XX
    Meraki AC Adapter for MR Series (XX = US, EU, UK, or AU)
  • MA-INJ-4-XX
    Cisco Meraki 802.3at PoE Injector (XX = US, EU, UK, or AU)
