| Brand | APC |
| Model | BX2200MI |
| Type | Line interactive |
| Rated Capacity | 1200Watts / 2200kVA |
| Nominal Input Voltage | 230V |
| Nominal Output Voltage | 230V |
| Input Frequency | 50/60 Hz +/- 5 Hz Auto-sensing |
| Backup Time | N/A |
| Transfer Time | 6 ms typical : 10 ms maximum |
| Display | None |
| Input Connections | IEC 60320 C14 |
| Output Connections | 4 universal outlets |
| Interface Port | 2 x RJ45 10/100/1000
1 x USb Type-B |
| Indicator & Audible Alam/ Protection | LED Status display with on line : on battery
Alarm when on battery : distinctive low battery alarm |
| Battery Type | Lead-acid battery |
| Waveform Type | Stepped approximation to a sinewave |
| Typical recharge time | 8hour(s) |
| Battery Replacement | 24V
*User replaceable battery not available |
| Features | N/A |
| Cord Length | 1.2meters |
| Environment | Operating Temperature : 0 - 40°C
Operating Relative Humidity : 0 - 95 (Non-condensing) %
Operating Elevation : 0 - 3000meters
Storage Temperature : -15 - 40°C
Storage Relative Humidity : 0 - 95 (Non-condensing) %
Storage Elevation : 0 - 3000meters
Audible noise at 1 meter from surface of unit : 40.0dBA
Protection Class : IP20 |
| Package Contents | N/A |
| Dimension | (W x D x H) : 14.00 x 39.00 x 19.00 cm |
| Net Weight | 12.00 KG |
| Package Dimension | (W x D x H) : 23.50 x 29.70 x 49.50 cm |
| Gross Weight | 13.30 KG |
| Volume | 34,548.53 cm3 |
