Cisco Meraki MS210-24P Cloud-Managed Switching for Branch and Small Campus

-9%

Product details of Cisco Meraki MS210-24P Cloud-Managed Switching for Branch and Small Campus

Interfaces

• 24 × 10/100/1000BASE-T Ethernet (RJ45)
• 4 × 1G SFP ports for uplinks
• 2 × stacking interfaces
• Auto negotiation and crossover detection

Management

• Managed via the Web with the Meraki cloud management platform
• Integrated with Meraki Wireless and complete portfolio of IT products and solutions
• Zero-touch remote deployment (no staging needed)
• Detailed historical per-port and per-client usage statistics
• Operating system, device, and hostname fingerprinting
• SNMPd and SYSLOG support for integration with other network management solutions
• Automatic firmware upgrades with scheduling control

Remote Diagnostics

• Email, SMS, and Mobile push notification alerts
• Ping, traceroute, cable testing, and link failure detection with alerting
• Remote packet capture
• Dynamic and interactive network discovery and topology
• Combined event and configuration change logs with instant search

Stacking

• Physical stacking of up to 8 switches with 160 Gbps stacking bandwidth on all models
• Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration

Ethernet Switching Capabilities

• 802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)
• 802.1Q VLAN and trunking support for up to 4,094 VLANs
• 802.1w, 802.1D Rapid Spanning Tree Protocol (RSTP, STP)
• STP Enhancements: BPDU guard, Root guard, Loop guard
• Broadcast storm control
• 802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP)
• 802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP)
• 802.3ad link aggregation with up to 8 ports per aggregate, Multichassis aggregates supported on stacked switches
• Port mirroring
• IGMP snooping for multicast filtering
• MAC forwarding entries: 16K

Security

• Integrated multi-factor authentication for cloud management platform
• Role-based access control (RBAC) with granular device and configuration control
• Corporate-wide password policy enforcement
• IEEE 802.1X RADIUS and MAB, hybrid authentication, and RADIUS server testing
• Single-Host/Multi-Domain/Multi-Host/Multi Authenticatio
• Port security: Sticky MAC, MAC whitelisting
• DHCP snooping, detection and blocking
• IPv4 and IPv6 ACLs

Performance

• Switching capacity: 128 Gbps
• Forwarding rate: 24 mpps
• Jumbo frame support (9600 byte Ethernet frame)
• Flow control support

Layer 3

• Static Routing
• Warm Spare (VRRP)
• DHCP Relay

Power

• Power input: 100-240 VAC, 47-63 Hz
• MS210-24: 15-24 W max, fanless
• MS210-24P: 21-448 W max
• 48V DC 802.3af/802.3at Power-over-Ethernet (PoE/PoE+) available on all ports (maximum of 30W per port for PoE+) for powered switches

Mounting

• 1U Rack-mountable with included rack mount hardware
• 2-post front mounting options available

Environment

• Operating temperature: -5°C to 50°C
• Humidity: 5 to 95% non-condensing
• Variable speed fans

Regulatory

• CSA-US (US, Canada)
• FCC (USA)
• IC (Canada)
• CE (Europe)
• RCM (Australia/New Zealand)
• RoHS
• For international availability, please contact sales@meraki.com

Warranty

• Full lifetime hardware warranty with next-day advanced replacement included

MTBF at 25°C

• MS210-24: 590,165
• MS210-24P: 391,648

Physical Specifications (H × W × D)

• MS210-24-HW
  • 1.72 × 19.08 × 9.84" (4.38 × 48.46 × 25cm)
  • 6.03 lb (2.73 kg)
• MS210-24P-HW
  • 1.72 × 19.08 × 9.84" (4.38 × 48.46 × 25cm)
  • 8.18 lb (3.71 kg)
