| PERFORMANCE |
| Processor | Intel® Core™ Ultra 7 155H, 16C (6P + 8E + 2LPE) / 22T, Max Turbo up to 4.8GHz, 24MB |
| AI PC Category | AI PC |
| NPU | Intel® AI Boost, up to 11 TOPS |
| Graphics | Integrated Intel® Arc™ Graphics |
| Chipset | Intel® SoC Platform |
| Memory | 16GB Soldered LPDDR5x-7467 |
| Memory Slots | Memory soldered to systemboard, no slots, dual-channel |
| Max Memory | 16GB soldered memory, not upgradable |
| Storage | 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Storage Support
| One drive, up to 1TB M.2 2242 SSD |
| Storage Slot | One M.2 2280 PCIe® 4.0 x4 slot |
| Card Reader | None |
| Optical | None |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC3306 codec |
| Speakers | Stereo speakers, 2W x4, optimized with Dolby Atmos®, Amplifier (AMP) |
| Camera | FHD 1080p + IR with E-shutter, ToF Sensor |
| Microphone | 4x, Array |
| Battery
| Integrated 65Wh |
| Power Adapter | 65W USB-C® Slim (Wall-mount) |
DESIGN |
| Display | 14" WUXGA (1920x1200) OLED 400nits Glossy / Anti-fingerprint, 100% DCI-P3, 60Hz, Dolby Vision®, TÜV Low Blue Light, DisplayHDR™ True Black 500, Glass, Touch |
| Touchscreen | OGS, 10-point Multi-touch |
| Color Calibration | None |
| Keyboard | Backlit, Thai |
| Touchpad | Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
| Case Color | Luna Grey |
| Surface Treatment | Aluminium Stamping (Anodized with Sandblasting) |
| Case Material | Aluminium (Top), Aluminium (Bottom) |
| Dimensions (WxDxH)
| 312 x 221 x 14.9 mm (12.28 x 8.7 x 0.59 inches) |
| Weight
| Starting at 1.43 kg (3.15 lbs) |
SOFTWARE |
| Operating System | Windows® 11 Home Single Language, English |
| Bundled Software | Office Home & Student 2021 |
| CONNECTIVITY |
| Ethernet | No Onboard Ethernet |
| WLAN + Bluetooth
| Wi-Fi® 6E, 802.11ax 2x2 + BT5.3 |
| Standard Ports | - 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.1 and DisplayPort™ 1.4
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
|
| Docking | Various docking solutions are supported via Thunderbolt™. For more compatible docking solutions, please visit Docking for Yoga® Slim 7 14IMH9 |
SECURITY & PRIVACY |
| Security Chip | Firmware TPM 2.0 |
| Fingerprint Reader | None |
| Other Security | - IR camera for Windows® Hello (facial recognition)
- E-shutter
|
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y Premium Care -IPPREM (ESS) |
| ACCESSORIES |
| Bundled Accessories
| None |
CERTIFICATIONS |
| Green Certifications
| - ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 6
- ErP Lot 26
- RoHS compliant
|
| Other Certifications | - Intel® Evo™ Platform
- Eyesafe® Certified 2.0
- TÜV Rheinland® Flicker Reduced
- TÜV Rheinland® Low Blue Light (Hardware Solution)
|
| Mil-Spec Test | MIL-STD-810H military test passed (21 test items) |
