ขนาดจอ 65 นิ้ว ขนาดจอ 75 นิ้ว ขนาดจอ 86 นิ้ว ขนาดจอ 65 นิ้ว เพิ่ม ROLLING STAND + IDEA SHARE KEY + REMOTE ขนาดจอ 75 นิ้ว เพิ่ม ROLLING STAND + IDEA SHARE KEY + REMOTE ขนาดจอ 86 นิ้ว เพิ่ม ROLLING STAND + IDEA SHARE KEY + REMOTE
สอบถามข้อมูลเพิ่มเติม
Share
Component
Device x 1 : 86-inch
Stylus pens x 2 : PET pen tip/anti-skid pen body/magnetic attachment
Cable : Power cable x 1
OPSOptional (i5/i7)
Rolling stand : Optional (support interface complies with the VESA standard)
Wall mounted bracket : Optional (support interface complies with the VESA standard)
IdeaHub Controller : Optional
Screen
Resolution : 4K UHD (3840 x 2160)
Viewing Angle : 178°
Glass Hardness : ≥ 7H
Screen Lamination : Zero-gap bonding
Color Depth : 10-bit (8-bit + FRC)
Backlight Type : D-LED
Number of Touch Points : 20
Screen Refresh Rate : 60 Hz
Aspect Ratio : 16:9
Eye Protection
Optical Anti-Blue Light : √
Anti-glare : √
Adaptive Brightness : √
TÜV Rheinland Low Blue Light (Hardware Solution) Certification : √
TÜV Rheinland Eye Comfort Certification : √
Writing
Writing Latency : 25 ms
Precision : ±1mm
Whiteboard Saving Mode : QR code scanning/Email/Local disk/USB flash drive
Intelligent Writing : √
Projection
Projection Mode : IdeaShare App IdeaShare Key Projection through the drop-down menu* HDMI, Type-C wired projection
* Mobile phone operating systems that support manual projection: EMUI 10.1.0 or later, Magic UI 3.1 or later.
Wireless Projection Performance : Up to 4K30
Wired Projection Performance : 4K60
Supported OS : Android/Windows/iOS/macOS
Annotate During Projection : √
Reverse Control : √
Wi-Fi
Dual-Wi-Fi Module : √
Wi-Fi Frequency : 2.4 GHz/5 GHz
Speaker
Frequency Domain : 100 Hz–20 kHz
Speaker Unit : 2 x full frequency speaker + 2 x high frequency speaker
Stereo : √
System
CPU : 4-core
RAM : 4 GB
Flash : 32 GB*
OS : Android 9.0/Windows 10**
**Available storage space will be less than the stated value as pre-installed software takes up a certain amount of space. **To use Windows 10, an OPS plug-in computer is required.
Terminal interface
Front-Panel Ports : Type-C x 1 Type-A x 2
Rear-Panel Ports : Type-A x 1; Type-B (reverse control) x 1 HDMI (input) x 2 HDMI (output) x 1 COM port x 1 RJ45 network port x 1 80-pin OPS port x 1 3.5 mm (line-in) x 1 3.5 mm (line-out) x 1
