Projection Technology:
Projection Technology:
RGB liquid crystal shutter projection system
Specifications of Main Parts:
LCD:
Native Resolution: 1080p
Size: 0.61” wide panel (D10, C2 Fine, 10Bit)
Projection Lens:
Projection Lens Type: Optical Zoom
(Manual) / Focus (Manual)
F-Number : 1.49 – 1.77
Focal Length: 18.2 – 29.2 mm
Zoom Ratio: 1 – 1.62
Throw Ratio: 1.32 – 2.15 (Wide – Tele)
Lamp:
Type: 200W UHE
Life (Normal / Eco)*1: 4,500 / 7,500 hours
Brightness:
White Light Output (Normal/Eco):
2,800 lm / 1,900 lm
Colour Light Output:
2,800 lm
Connectivity:
USB Interface:
USB Type B: 1 (For firmware update and copy OSD settings)
Network:
Wireless: Yes (SMP function only)
Digital Input:
HDMI: 1
Audio Out:
Stereo Mini x 1
Control I/O:
RS-232C: N/A
Trigger Out (12V): N/A
Contrast Ratio:
Contrast Ratio:
35,000:1
Screen Size (Projected Distance):
Zoom : Wide:
40” to 500” [1.15 to 14.83 m]
Zoom : Tele:
40” to 500” [1.89 to 24 m]
Standard Size:
80” screen 2.34 to 3.81 m
Geometric Correction:
Vertical Keystone:
±30 degrees
Adjustment Functions:
Picture In Picture:
N/A
Aspect Mode:
Yes (Auto / Normal / Full / Zoom )
Frame Interpolation:
Off / Low / Normal / High
Image Enhancement:
Image Preset Mode:
Yes
Mpeg Noise Reduction:
Yes
Detail Enhancement:
Yes
Start-Up Period:
Start-Up Period:
Under 15 seconds
Warm-up period: 30 seconds
Operating Temperature:
Operating Temperature:
5 - 35 °C <41 - 95 °F> (0m / 0ft - 2,286m / 7,500ft)
5 - 30 °C <41 - 86 °F> (Over 2,286m / 7,500ft)
(20% - 80% Humidity, No Condensation)
Operating Altitude:
Operating Altitude:
0 m to 3,048 m <0 ft to 10,000 ft> (Over 1,500 m / 4,921 ft : with High Altitude mode)
Dimension Excluding Feet (W x H x D):
Dimension Excluding Feet (W x H x D):
333 x 123 x 275 mm
Power:
Power Consumption:
Lamp On (Normal/ECO): 301W / 268W
Network Standby: N/A
Energy Saving: 0.3W
Weight:
Weight:
Approx. 4.1kg
Direct Power On/Off:
Direct Power On/Off:
Yes / N/A
Wireless Specifications (Smart Media Player Function):
Supported Speed For Each Mode:
IEEE 802.11a (5 GHz),
IEEE 802.11b (2.4 GHz),
IEEE 802.11g (2.4 GHz),
IEEE 802.11n (2.4 GHz and 5 GHz),
IEEE 802.11ac (5 GHz)
Wireless LAN Security:
WPA2/WPA3 PSK (AES)
Wi-Fi Generation:
Wi-Fi 5
Supported OS:
Android OS
Video Output Resolution:
Up to 3840 x 2160 60fps 4:4:4
Cool Down Period:
Cool Down Period:
Under 5 seconds
Fan Noise:
Fan Noise (Normal / Eco):
36dB / 28dB
Lens Shift Range:
Vertical Lens Shift:
±96.3 % (H Center, Powered)
Horizontal Lens Shift:
±47.1 % (V Center, Powered)
Projectors Facets:
4K PRO-UHD, Projectors Facets:
Yes
Features, Projectors Facets:
Wifi
4k Pro UHD
Laser / Lamp, Projectors Facets:
Lamp
Screen Size, Projectors Facets:
50 - 300
Projector Primary Usage, Projectors Facets:
Home Theater
Resolution, Projectors Facets:
4K PRO-UHD
Contrast Ratio, Projectors Facets:
200,000:1
Brightness Range Lumens, Projectors Facets:
2000
Power Supply Voltage:
Power Supply Voltage:
100 - 240 V AC +/- 10%, 50/60 Hz
