Cisco Meraki MR53 802.11ac Wave 2 with Bluetooth Beacon & Multigigabit Ethernet

-20%

Product details of Cisco Meraki MR53 802.11ac Wave 2 with Bluetooth Beacon & Multigigabit Ethernet

Radios

• 2.4 GHz 802.11b/g/n client access radio
• 5 GHz 802.11a/n/ac client access radio
• 2.4 & 5 GHz dual-band WIDS/WIPS, spectrum analysis, & location analytics radio
• 2.4 GHz Bluetooth radio with Bluetooth Low Energy (BLE) and Beacon support
• Concurrent operation of all four radios
• Max aggregate frame rate 2.5 Gbit/s
• Supported frequency bands (country-specific restrictions apply):
  • 2.412-2.484 GHz
  • 5.150-5.250 GHz (UNII-1)
  • 5.250-5.350 GHz (UNII-2)
  • 5.470-5.600, 5.660-5.725 (UNII-2e)
  • 5.725-5.825 GHz (UNII-3)

Antenna

• Integrated omni-directional antennas (5 dBi gain at 2.4 GHz, 6.2 dBi gain at 5 GHz)
• Individual antenna elements for each radio

802.11ac Wave 2 & 802.11n Capabilities

• 4x4 multiple input, multiple output (MIMO) with four spatial streams
• SU-MIMO and MU-MIMO support
• Maximal ratio combining (MRC) & beamforming
• 20 & 40 MHz channels (802.11n); 20, 40, 80, and 160MHz channels (802.11ac)
• Up to 256-QAM on both 2.4 & 5 GHz
• Packet aggregation

Power

• Power over Ethernet: 37 - 57 V (802.3at required; functionality-restricted 802.3af mode supported)
• Alternative 12V DC input
• Power consumption: 21 W max (802.3at)
• Power over Ethernet injector and DC adapter sold separately

Interfaces

• 1× 100/1000/2.5G BASE-T Ethernet & 1× 10/100/1000 BASE-T Ethernet (RJ45)
• 1 × DC power connector (5.5mm x 2.5mm, center positive)

Mounting

• All standard mounting hardware included
• Desktop, ceiling, and wall mount capable
• Ceiling tile rail (9/16, 15/16 or 1 ½" flush or recessed rails), assorted cable junction boxes
• Bubble level on mounting cradle for accurate horizontal wall mounting

Physical Security

• Two security screw options (included)
• Kensington lock hard point
• Concealed mount plate with anti-tamper cable bay

Environment

• Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)
• Humidity: 5 to 95% non-condensing

Physical Dimensions

• 10.56” x 6.38” x 1.58” (268.2 mm x 162.0 mm x 38.8 mm), not including deskmount feet or mount plate
• Weight: 28.9 oz (820g)

Security

• Integrated Layer 7 firewall with mobile device policy management
• Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal
• Flexible guest access with device isolation
• VLAN tagging (802.1q) and tunneling with IPsec VPN
• PCI compliance reporting
• WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X
• EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
• TKIP and AES encryption
• Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration
• Cisco ISE integration for Guest access and BYOD Posturing

Quality of Service

• Advanced Power Save (U-APSD)
• WMM Access Categories with DSCP and 802.1p support
• Layer 7 application traffic identification and shaping

Mobility

• PMK, OKC, and 802.11r for fast Layer 2 roaming
• Distributed or centralized layer 3 roaming

Analytics

• Embedded location analytics reporting and device tracking
• Global L7 traffic analytics reporting per network, per device, & per application

Warranty

• Lifetime hardware warranty with advanced replacement included

Ordering Information

• MR53-HW
  Meraki MR53 Cloud Managed 802.11ac AP
• MA-PWR-30W-XX
  Meraki AC Adapter for MR Series (XX = US, EU, UK, or AU)
• MA-INJ-5-XX
  Cisco Meraki Multigigabit 802.3at PoE Injector (XX = US, EU, UK, or AU)
