CPU | CPU Model | Intel ATOM C3538 |
|---|
| CPU Architecture | x64 64-bit |
|---|
| CPU Frequency | Quad-Core 2.1GHz |
|---|
Memory | Memory | 8GB SO-DIMM DDR4 |
|---|
| Memory Module Pre-installed | 8GB (1x 8GB) |
|---|
| Total Memory Slots | 4 |
|---|
| Memory Expandable up to | 128GB (4x 32GB) |
|---|
| Flash Memory | 8GB eMMC |
|---|
Storage | Drive Bays | 4 |
|---|
| Compatible Drive Type | - 3.5" SATA HDD
- 2.5" SATA HDD
- 2.5" SATA SSD
|
|---|
| Maximum Drive Bays with Expansion Unit | 20 |
|---|
| Supports Hot Swappable Drives |
|
|---|
External Ports | Expansion | 4x USB 3.2 Gen 1 |
|---|
| Network | - 2x Gigabit Ethernet (1G/100M)
- 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
|
|---|
| PCIe Expansion Slots | PCIe 3.0 x8 slot (black, x4 link) |
|---|
| Multimedia Output | N/A |
|---|
Others | System Fan | 2x 40mm |
|---|
| Power Supply Unit / Adapter | AS6504RS: 250W x1 AS6504RD: 250W x2 AS6504RS x1 / AS6504RD x2 |
|---|
| Input Power Voltage | 100V to 240V AC |
|---|
| Redundant power supply |
|
|---|
| Service LED Indicator |
|
|---|
| Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS |
|---|
| Warranty | 3 Years |
|---|
Operation | Power Consumption | AS6504RS: 47.7W (Operation) 28.4W (Disk Hibernation); AS6504RD: 65W (Operation) 42.4W (Disk Hibernation); |
|---|
| Noise Level | - |
|---|
| Operation Temperature | 0°C~40°C (32°F~104°F) |
|---|
| Storage Temperature | -20°C~70°C (-4°F~158°F) |
|---|
| Humidity | 5% to 95% RH |
|---|
Size and Weight | Size | 44(H) x 439(W) x 515(D) mm |
|---|
| Weight | AS6504RS: 7.85kg / 17.27 lbs; AS6504RD: 9.3 kg / 20.46 lbs |
|---|
