| PERFORMANCE |
| Processor | Intel® Core i5-13420H, 8C (4P + 4E) / 12T, P-core 2.1 / 4.6GHz, E-core 1.5 / 3.4GHz, 12MB |
| Graphics | Integrated Intel® UHD Graphics |
| Chipset | Intel® SoC Platform |
| Memory | 8GB Soldered DDR4-3200 + 8GB SO-DIMM DDR4-3200 |
| Memory Slots | One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable |
| Max Memory
| Up to 16GB (8GB soldered + 8GB SO-DIMM) DDR4-3200 offering |
| Storage | 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Storage Slot | Models with 38Wh battery: one 2.5" drive slot + one M.2 slot • One 2.5" SATA HDD slot • One M.2 2280 PCIe® 4.0 x4 slot |
| Max Storage Support
| Models with 38Wh battery: up to two drives, 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • M.2 2242 SSD up to 1TB |
| Optical | None |
| Card Reader | None |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
| Speakers | Stereo speakers, 1.5W x2, Dolby Audio™ |
| Microphone | 2x, Array |
| Camera | HD 720p with Privacy Shutter |
| Battery | 38Wh |
| Power Adapter | 65W Round Tip (3-pin) |
| DESIGN |
| Display | 15.6" FHD (1920x1080) TN 250nits Anti-glare, 45% NTSC |
| Touchscreen | None |
| Screen-to-Body Ratio | 87% |
| Pen | Pen Not Supported |
| Keyboard | Non-backlit, Thai |
| Touchpad | Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 62 x 104 mm (2.44 x 4.09 inches) |
| Dimensions (WxDxH)
| 359.2 x 235.8 x 19.9 mm (14.14 x 9.28 x 0.78 inches) |
| Weight
| Starting at 1.65 kg (3.64 lbs) |
| Case Color | Business Black |
| Case Material | PC-ABS (Top), PC-ABS (Bottom) |
| Surface Treatment | Texture |
| SOFTWARE |
| Operating System | None |
| Bundled Software | None |
| CONNECTIVITY |
| WLAN + Bluetooth | Wi-Fi® 6, 802.11ax 2x2 + BT5.2 |
| WWAN | Non-WWAN |
| Ethernet | 100/1000M (RJ-45) |
| Standard Ports | - 1x USB 2.0
- 1x USB 3.2 Gen 1
- 1x USB-C® 3.2 Gen 1 (support data transfer, Power Delivery (20V only) and DisplayPort™ 1.2)
- 1x HDMI® 1.4b
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (RJ-45)
- 1x Power connector
|
| Docking | Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Lenovo® V15 G4 IRU |
| SECURITY & PRIVACY |
| Security Chip | Firmware TPM 2.0 Enabled |
| Physical Locks | Kensington® Nano Security Slot, 2.5 x 6 mm |
| Fingerprint Reader | None |
| Other Security | Camera privacy shutter |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 1Y Onsite upgrade from 1Y Courier/Carry-in |
| ACCESSORIES |
| Bundled Accessories | None |
| CERTIFICATIONS |
| Green Certifications | - ErP Lot 6/26
- FSC certified package
- RoHS compliant
|
| Mil-Spec Test | MIL-STD-810H military test passed |
| Other Certifications | TÜV Rheinland® Low Blue Light (Software Solution) |
| MODEL INFORMATION |
| Model | 83A100D6TA |
| Machine Type | 83A1 |
| Region | ASEAN |
| Country/Region | Thailand |
| TopSeller | Yes |
| EAN / UPC / JAN | 197531040862 |
| Announce Date | 2023-09-14 |
| End of Support | 2029-11-03 |
