General
Capacity (VA / Watts) : 6000 / 6000
Phase : Single Phase
Topology : HF Transformer
Surge Power (Watts) : 12000
Parallel Connection : Yes
Maximum Number of Inverters in Parallel : 4
AC Input
Generator Compatible : Yes
Rated Input Voltage (Vac) : 230
Input Voltage Range (On UPS) (Vac) : 170 ~ 280
Input Voltage Range (On APL) (Vac) : 90 ~ 280
Rated Input Frequency (Hz) : 50 / 60
Input Frequency Range (Hz) : 45 ~ 65
AC Input Frequency Detection : Auto-sensing
AC Input Connector Type : Hardwire Terminal Block
PV Input
Nominal Input Power (Watts) : 6000
Maximum Input Voltage (Vdc) : 500
Number of MPPT : 2
Maximum PV Power (Watts) : 8000
Maximum MPPT Current (A) : 12 / 12
Maximum DC Short Circuit Current (A) : 12 / 12
MPP Voltage Range (Vdc) : 270 ~ 450
AC Output
Maximum Efficiency (%) : 93%
Output Waveform : Pure Sine Wave
Output Voltage(s) (Vac) : 230 ± 5%
Output Frequency (Hz) : 50 ± 0.5% / 60 ± 0.5%
Maximum Output Power (W) : 6000
Typical Transfer Time (On UPS) (ms) : 10
Typical Transfer Time (On APL) (ms) : 20
Harmonic Distortion (Linear Load) : THD ≦3%
Harmonic Distortion (Non-linear Load) : THD ≦8%
Output Short Circuit Protection : Circuit Breaker
Battery
Battery Voltage (Vdc) : 48
Overcharge Protection (Vdc) : 66
Charger
Maximum Solar Charging Current (A) : 120
Maximum AC Charging Current (A) : 100
Maximum Charging Current (A) : 120
Management & Communications
LCD Panel : Yes
LCD Types : Color LCD
LED Indicators : Yes
Communication Interface : RS232 x 1, Dry Contact x 1
Physical
Enclosure Construction : Metal
Color : White
Degree of Protection : IP20
Dimensions (WxHxD) (mm.) : 445 x 300 x 115
Weight (kg.) : 11.6
Environmental
Operating Temperature (°C) : 0 ~ 50
Operating Relative Humidity (Non-condensing) (%) : 5 ~ 95
Storage Temperature (°C) : -15 ~ 60
Storage Relative Humidity (Non-condensing) (%) : 5 ~ 95
Cooling Method : Fan
Certifications
Certifications : CE, IEC 62109-1/2, EN 61000-6-2, EN 61000-6-4, IEC 61683
RoHS : Yes
WARRANTY
Product Warranty Period (Year) : 2
