EPSON Projector V11HB56052

Projector Specifications

Projection Technology

• System: RGB Liquid Crystal Shutter Projection System (3LCD)

Brightness

• White Light Output (Normal / Eco): 3,800 lm / 2,500 lm

• Colour Light Output: 3,800 lm

• Light Output (Center): 4,000 lm

Connectivity

• Wireless LAN: Optional (with ELPAP11)

• HDMI Type A: 2 ports (HDCP 1.4)

• USB Type A: 1 port

  • 480 Mbps (for PC Free, Firmware Update, Copy OSD Settings)

  • 5V/2A Power Supply

• USB Type B: 1 port (for Firmware Update, Copy OSD Settings)

Contrast Ratio

• Contrast Ratio: 16,000:1

Screen Size (Projected Distance)

• Zoom (Wide): 30” – 300” [0.89 – 9.12 m]

• Zoom (Tele): 30” – 300” [1.07 – 10.95 m]

Geometric Correction

• Vertical Keystone: ±30°

• Horizontal Keystone: ±30°

Operating Conditions

• Temperature:

  • Low Altitude (0–2,286 m): 5–40 °C (41–104 °F)

  • High Altitude (>2,286 m): 5–35 °C (41–95 °F)

• Humidity: 20%–80% (No Condensation)

• Operating Altitude: 0–3,048 m (0–10,000 ft) with High Altitude Mode

Start-Up / Cool Down

• Start-Up Period: Less than 7 seconds (Epson Logo)

• Warm-Up Period: 30 seconds

• Cool Down Period: Instant Off

Audio

• Internal Speaker: Monaural 2W x 1

Maintenance

• Air Filter Cycle: 6,000 hours (Normal) / 12,000 hours (Eco)

Noise Level

• Fan Noise (Normal / Eco): 37 dB / 28 dB

Power

• Power Consumption (Normal / Extended): 332 W / 231 W

• Standby Power (Normal / Eco): 2.0 W / 0.3 W

• Power Supply: 100–240 V AC ±10%, 50/60 Hz

• Direct Power On / Off: Yes

Dimensions & Weight

• Dimensions (W x D x H): 302 × 234 × 77 mm (excluding feet)

• Weight: Approx. 2.5 kg

Wireless Specifications (Optional)

• Supported Standard: IEEE 802.11 a/b/g/n

• Supported Mode: Infrastructure, Simple AP (Wi-Fi Direct)

• Security Type:

  • Infrastructure: Open, WPA2 / WPA3-PSK

  • Wi-Fi Direct: OPEN, WPA2-PSK (AES)

Main Components

LCD Panel:

• Size: 0.55” (C2 Fine)

• Driving Method: Poly-silicon TFT Active Matrix

• Pixel Number: 786,432 dots (1024 × 768) × 3

• Native Resolution: XGA

• Aspect Ratio: 4:3

• Pixel Arrangement: Cross Stripe

Light Source (Lamp):

• Type: 210 W UHE

• Life: 6,000 hours (Normal) / 12,000 hours (Eco)

Projection Lens:

• Type: Optical Zoom (Manual) / Focus (Manual)

• F-Number: 1.49 – 1.72

• Focal Length: 16.9 – 20.28 mm

• Zoom Ratio: 1.0 – 1.2

• Throw Ratio: 1.48 – 1.77
